M7719 Series DC-DC Power Supplies

Key Features
Product Type:Power Supply (Converter)
Input:18-50DC
Output(s):One
Output Power:200W
Efficiency:90%
Operating Temp.:-95°C to 5°C
Designed to Meet:MIL-STD-704 | MIL-STD-810 | MIL-STD-461
Standard Configurations
Model Power Output 1
M7719-101 120W 12V @ 10A
M7719-102 150W 15V @ 10A
M7719-103 192W 24V @ 8A
M7719-104 196W 28V @ 7.14A
M7719 Additional configurations available

* All of our products can be configured to comply with EU REACH regulations. Contact Us today to learn more.

Base Specifications
Form Factor:Baseplate Mount
Weight:5.64oz160g
Dimensions:3.26" X 1.83" X 0.72"82.8mm X 46.48mm X 18.29mm
*

Product specifications and features subject to change without notice.
Please contact our factory before placing order.

Output Range(V min to V max @ A max)
#1 12V to 28V @ 10A
Description

SINGLE-OUTPUT, 200W DC TO DC BASEPLATE COOLED POWER SUPPLY
